Ultra-compact Bluetooth module with 3 master and 3 slave connections, BLE 5.2 | ANS-BT105M
The ANS-BT105M is a BLE Bluetooth 5.2 module that supports multiple profiles such as GATT, HID, and ATT. It uses UART as its programming interface, allowing users to read and write the module’s configuration information via AT commands. This module boasts high performance and strong compatibility, easily meeting various connectivity and data transmission needs.
| Model | ANS-BT105M |
| Bluetooth Standard | BLE 5.2 |
| Profiles | GATT |
| Dimension (mm) | 8.5mm x 9.5mm x 2mm |
| Interface | UART |
| Antenna | Built-in PCB onboard antenna |
| Supply Voltage | 1.8V~3.6V |
| Transmit Power | +6 dBm(max) |
| Receive Sensitivity | -92dBm @0.1%BER |
| Baud rate | Default 115200bps，Support from 1200bps to 921.6Kbps. |
| Communication mode | AT command mode, pass-through mode |
Applications of ultra-compact Bluetooth modules:
- Industrial data transmission
- Health and medical devices
- Measurement and monitoring systems
- Industrial sensors and control
- Bluetooth car keys
- Barcode scanners
- Bluetooth mesh networks
- Lighting equipment
- Wireless transmission for home appliances
