Bluetooth 5.2 master-slave integrated serial port pass-through small-size HID module | ANS-BT103S
The ANS-BT103S is a small-sized BLE Bluetooth 5.2 module independently developed by Anshuo Technology. It supports HID, GATT, ATT, and other configuration files, uses UART as its programming interface, and allows users to read or write the module’s configuration via UART using AT commands. Over-the-air upgrades are supported. It supports Bluetooth master/slave integration, HID, and custom development.
Download Center
Applications of Small-Size BLE 5.2 Low-Power Modules:
- Industrial Data Transmission
- Health and Medical Devices
- Measurement and Monitoring Systems
- Industrial Sensors and Controls
- Bluetooth Car Keys
- Barcode Scanners
- Bluetooth Mesh Networking
- Lighting Fixtures
- Wireless Transmission for Home Appliances
Product parameters
| Model | ANS-BT103S |
| Bluetooth Standard | BLE 5.2 |
| Profiles | GATT |
| Dimension (mm) | 16mm x 10mm x 2mm |
| Interface | UART |
| Antenna | Built-in PCB onboard antenna |
| Supply Voltage | 3.0V~3.6V |
| Transmit Power | +6 dBm(max) |
| Receive Sensitivity | -92dBm @0.1%BER |
| Baud rate | Default 115200bps，Support from 1200bps to 921.6Kbps. |
| Communication mode | AT command mode, pass-through mode |
